Module-Drive Train Control C1 (D3872A)

Harness-Family: Suspension_Jumper

Color: BLUE

Gender: FEMALE

Part Number: 7283-6456-90

Part Description: KAIZEN YESC SUB ASSEMBLY

Connector No: D3872A

Option: Standard

Repair Kit Part Number: 68065019AA

Cavity Count: 16

Fig 1: Module-Drive Train Control C1 Connector End View
GCWD1006351Courtesy of CHRYSLER
Fig 2: Module-Drive Train Control C1 Component Location
GCWD1163808Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 T301 DG/YL 1.0 SWITCHED BATTERY SOLENOID SUPPLY N/A
2 G95 VT/BR 0.50 NEUTRAL INDICATOR N/A
3 T313 YL/LG 0.50 MODE SENSOR SIGNAL N/A
4 F946 PK/LG 0.50 FUSED IGNITION RUN/START CONTROL OUTPUT N/A
5 D302 DG 0.35 CAN C (-) N/A
6 D301 WT 0.35 CAN C (+) N/A
7 K77 BR/WT 0.50 TRANSFER CASE POSITION SENSOR INPUT N/A
8 K977 BR/WT 0.50 MODE SELECT N/A
9 T317 YL/TN 1.0 STEP MOTOR CONTROL D N/A
10 K594 BR/LG 0.50 DRIVETRAIN SENSOR RETURN N/A
11 K504 BR 0.50 DRIVETRAIN 5 VOLT SUPPLY N/A
(1) Pins not listed are not used for this connector
