Module-Transmission Control (D2735A)

Harness-Family: Engine

Color: BLACK

Gender: FEMALE

Part Number: 09_4308_01

Part Description: Not Available

Connector No: D2735A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 16

Fig 1: Module-Transmission Control Connector End View

Courtesy of CHRYSLER

Fig 2: Module-Transmission Control Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

D440

WT/BR

0.50

DATA BUS(-) ESHIFT

N/A

D441

WT/OR

0.50

DATA BUS(+) ESHIFT

N/A

D29

VT/WT

0.50

CAN C (+)

N/A

D30

0.50

CAN C (-)

N/A

PK/WT

0.50

IGNITION OFF/RUN/START CONTROL OUTPUT

N/A

A190

YL/RD

0.75

FUSED B(+)

5.7L

Z903

0.75

GROUND

5.7L

T824

YL/DB

0.50

TRS PARK SIGNAL

N/A

⁽¹⁾	Pins not listed are not used for this connector
