Module, Tire Pressure Monitoring (TPM): Description: Description
WARNING: This page is about a different car, the 2015 RAM ProMaster 3500, 2015 RAM ProMaster 2500, and 2015 RAM ProMaster 1500. However, it is still accessible from the selected car via links, so may be relevant.
The Tire Pressure Monitoring (TPM) module is located under the front of the vehicle, beneath the engine compartment.
The Tire Pressure Monitoring System (TPMS) monitors the tire pressure of each tire and alerts the driver, through the instrument panel cluster, when a low pressure tire condition exists or a TPMS abnormal condition exists. The TPMS consists of the following components:
- Tire Pressure Monitoring (TPM) module.
- Four tire pressure sensors.
- Instrument panel cluster.
