Module-Body Control C1/A

Harness-Family: HDLP_Dash

Color: BLACK

Gender: FEMALE

Part Number: 13850155_13850159

Part Description: Not Available

Connector No: D3806A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 24

Fig 1: Module-Body Control C1/a Connector End View
GCWD1012242Courtesy of CHRYSLER
Fig 2: Module-Body Control C1/a Component Location
GCWD1220142Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 L89 WH/YE 0.75 LEFT FRONT FOG LAMP CONTROL N/A
2 L78 WH/BU 0.75 RIGHT FRONT PARK LAMP DRIVER N/A
3 L43 WH/DB 1.0 LEFT LOW BEAM DRIVER N/A
4 L141 WH/PK 0.75 LEFT FRONT SIDEMARKER LAMP CONTROL N/A
5 L158 PK/BG 0.50 RIGHT LED SIDE MARKER CONTROL N/A
6 W7 BN/GY 0.50 WIPER PARK SWITCH SENSE N/A
7 L159 PK/WH 0.50 LEFT LED SIDE MARKER CONTROL N/A
8 W1 BN/BG 0.35 WASHER FLUID LEVEL SWITCH SENSE N/A
9 W11 BN/BG 0.35 LOW WASH SW RTN 1 N/A
10 L33 WH/GN 0.75 LEFT HIGH BEAM DRIVER N/A
11 G70 VT/BU 0.75 HOOD AJAR SWITCH SENSE N/A
12 W8 BN/WH 0.50 WIPER ON/OFF RELAY CONTROL N/A
13 L60 WH/GY 0.75 RIGHT FRONT TURN LAMP DRIVER N/A
15 W10 BN 0.75 FRONT WASHER PUMP MOTOR CONTROL N/A
18 K617 BN 0.50 RUN/START RELAY CONTROL N/A
19 K90 BU/BG 0.50 STARTER RELAY CONTROL N/A
20 W2 BN/GN 0.50 WIPER HIGH/LOW RELAY CONTROL N/A
23 X4 DG/WH 0.50 HORN RELAY CONTROL N/A
(1) Pins not listed are not used for this connector
