Module-Body Control C2/B

Harness-Family: Body

Color: BLACK

Gender: FEMALE

Part Number: 7283-6469-30

Part Description: Not Available

Connector No: D3806B

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 4

Fig 1: Module-Body Control C2/b Connector End View

Courtesy of CHRYSLER

Fig 2: Module-Body Control C2/b Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

Z922

2.0

GROUND

N/A

A904

RD/YE

3.0

FUSED B(+)

N/A

⁽¹⁾	Pins not listed are not used for this connector
