Module-Fuel Pump Control

Harness-Family: Body

Color: GRAY

Gender: FEMALE

Part Number: 13669205

Part Description: Not Available

Connector No: D2792A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 8

Fig 1: Module-Fuel Pump Control Connector End View

Courtesy of CHRYSLER

Fig 2: Module-Fuel Pump Control Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

N11

DB/DG

0.50

FPCM PWM CONTROL

N/A

Z924

3.0

GROUND

N/A

Z31

0.35

GROUND

N/A

DB/OG

3.0

FUEL PUMP CONTROL OUTPUT

N/A

N13

DB/OG

2.5

FUEL PUMP PWM CONTROL

N/A

N12

DB/GN

0.50

FPCM PWM FEEDBACK

N/A

N14

VT/BU

2.5

FUEL PUMP RETURN

N/A

⁽¹⁾	Pins not listed are not used for this connector
