Module-Body Control C4/D (Standard) Connector End View (D3806D)

Harness-Family: HDLP_Dash

Color: NATURAL

Gender: FEMALE

Part Number: 13850156_13850159

Part Description: Not Available

Connector No: D3806D

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Body Control C4/d Connector End View (Standard)
GCWD1014436Courtesy of CHRYSLER
Fig 2: Module-Body Control C4/d Component Location (Standard)
GCWD1231081Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 L33 WH/GN 0.50 LEFT HIGH BEAM DRIVER N/A
2 L44 WH/BG 0.75 RIGHT LOW BEAM DRIVER N/A
3 L78 WH/OG 0.50 RIGHT FRONT PARK LAMP DRIVER N/A
13 L90 WH/OG 0.50 RIGHT FRONT FOG LAMP CONTROL N/A
14 L61 WH/GN 0.50 LEFT FRONT TURN LAMP DRIVER N/A
15 L58 WH/YE 0.50 LEFT DRL LAMP DRIVER N/A
18 B15 WH/VT 0.50 BRAKE SIGNAL 1 N/A
21 B20 DG/OG 0.50 BRAKE FLUID LEVEL SIGNAL N/A
22 G31 VT/GN 0.50 AAT SIGNAL N/A
23 G931 VT/BN 0.50 SENSOR GROUND N/A
24 T824 YE/DB 0.50 TRS PARK SIGNAL N/A
(1) Pins not listed are not used for this connector
