Module-Drive Train Control C2 (Standard) Connector End View (D3872B)

Harness-Family: Suspension_Jumper

Color: LIGHT GRAY

Gender: FEMALE

Part Number: 15466671

Part Description: Not Available

Connector No: D3872B

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Drive Train Control C2 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Drive Train Control C2 Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

T316

YE/GY

2.0

SHIFT MOTOR CONTROL B

N/A

T315

YE/BN

2.0

SHIFT MOTOR CONTROL A

N/A

A194

2.0

FUSED B(+)

N/A

⁽¹⁾	Pins not listed are not used for this connector
