Module-Drive Train Control C1 (Standard) Connector End View (D3872A)

Harness-Family: Suspension_Jumper

Color: BLUE

Gender: FEMALE

Part Number: 7283-6456-90

Part Description: Not Available

Connector No: D3872A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Drive Train Control C1 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Drive Train Control C1 Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

T301

DG/YE

1.0

SWITCHED BATTERY SOLENOID SUPPLY

N/A

G95

VT/BN

0.50

NEUTRAL INDICATOR

N/A

F946

PK/GN

0.50

FUSED IGNITION RUN/START CONTROL OUTPUT

N/A

D302

0.35

CAN C (-)

N/A

D301

0.35

CAN C (+)

N/A

K77

BN/WH

0.50

TRANSFER CASE POSITION SENSOR INPUT

N/A

K977

BN/WH

0.50

MODE SELECT

N/A

T317

YE/BG

1.0

STEP MOTOR CONTROL D

N/A

K594

BN/GN

0.50

DRIVETRAIN SENSOR RETURN

N/A

K504

0.50

DRIVETRAIN 5 VOLT SUPPLY

N/A

⁽¹⁾	Pins not listed are not used for this connector
