Fan Module-Radiator Cooling C2 (D3022B)

Harness-Family: HDLP_Dash

Color: BLACK

Gender: FEMALE

Part Number: 12033769

Part Description: CONNECTOR ASSEMBLY - M/P P2S

Connector No: D3022B

Option: Standard

Repair Kit Part Number: 68018943AA

Cavity Count: 2

Fig 1: Fan Module-Radiator Cooling C2 Connector End View

Courtesy of CHRYSLER

Fig 2: Fan Module-Radiator Cooling C2 Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

N23

DB/DG

4.0

LOW SPEED RAD FAN CONTROL

N/A

Z910

4.0

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
