Module-Trailer Tow C1 (Standard) Connector End View (D2399A)

Harness-Family: IP

Color: LIGHT GRAY

Gender: FEMALE

Part Number: 7283-6469-40

Part Description: Not Available

Connector No: D2399A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Trailer Tow C1 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Trailer Tow C1 Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

Z911

2.0

GROUND

N/A

B15

DG/WH

0.50

BRAKE SIGNAL 1

N/A

A400

BG/RD

2.0

FUSED B(+)

N/A

B400

2.0

TRAILER TOW ELECTRIC BRAKE OUTPUT

N/A

⁽¹⁾	Pins not listed are not used for this connector
