Relay-PCR Control (On PCB) (Standard) Connector End View (D917)

Harness-Family: PDC_Underhood

Color: NA

Gender: FEMALE

Part Number: NON-SERVICEABLE-PCB

Part Description: Not Available

Connector No: D917

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Relay-Pcr Control (on Pcb) Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Relay-Pcr Control (on Pcb) Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

T762

INTERNAL

STOP/START PCR RELAY CONTROL

N/A

T750

INTERNAL

STARTER RELAY OUTPUT

N/A

T760

INTERNAL

STOP/START RELAY CONTROL

N/A

⁽¹⁾	Pins not listed are not used for this connector
