Varistor-Passenger Horizontal (Standard) Connector End View (D23521A)

Harness-Family: Seat_Cshn_Pass

Color: NA

Gender: FEMALE

Part Number: 984983

Part Description: Not Available

Connector No: D23521A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Varistor-Passenger Horizontal Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Varistor-Passenger Horizontal Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

P14

GN/WH

1.0

PASSENGER SEAT HORIZONTAL FORWARD DRIVER

N/A

P16

GN/DG

1.0

PASSENGER SEAT HORIZONTAL REARWARD DRIVER

N/A

⁽¹⁾	Pins not listed are not used for this connector
