Fan, Cooling: Description: With-Max-Cooling
The 850W cooling fan is integrated into the fan shroud and is located between the radiator (1) and the engine.
The fan is controlled by a duty cycle signal from the PCM.
The signal is sent the cooling fan control module located on the cooling fan motor assembly. The module deciphers the signal and controls the fan motor to set the speed required for sufficient cooling.
