Module-Central Vision Processing C1 (Standard) Connector End View (D2999A)

Harness-Family: IP

Color: BLACK

Gender: FEMALE

Part Number: 2065230121

Part Description: Not Available

Connector No: D2999A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Central Vision Processing C1 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Central Vision Processing C1 Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

F924

DB/GN

0.35

RUN RELAY CONTROL

SURROUND VIEW CAMERA

D368

DB/WH

0.35

CAN IHS (+)

SURROUND VIEW CAMERA

D367

0.35

CAN IHS (-)

SURROUND VIEW CAMERA

Z930

0.35

GROUND

SURROUND VIEW CAMERA

⁽¹⁾	Pins not listed are not used for this connector
