Module-Inverter (Standard) Connector End View (D3920A)

Harness-Family: IP

Color: BLACK

Gender: FEMALE

Part Number: 1456471-1

Part Description: Not Available

Connector No: D3920A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Inverter Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Inverter Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

P802

110 VOLT AC LINE 2

115V POWER OUTLET

F103

2.5

IGNITION RUN/ACC RELAY CONTROL

115V POWER OUTLET

P801

110 VOLT AC LINE 1

115V POWER OUTLET

P806

YE/GN

0.35

INVERTER STATUS INDICATOR DRIVER

115V POWER OUTLET

Z930

2.5

GROUND

115V POWER OUTLET

⁽¹⁾	Pins not listed are not used for this connector
