Crankshaft Position Sensor: Service and Repair

Crankshaft Position Sensor:

REMOVAL

1. Remove mounting screws of the Crankshaft Position Sensor (CPS).
2. Disconnect the CPS wiring connector.
3. Remove the position sensor.

INSTALLATION

1. Install CPS.
2. Torque mounting screws to 71 lb. in. (8 N-m).
3. Install wiring connector to CPS.
