Test Procedures
- Lock and unlock doors several times, using switches in each door. If all locks work normally, go to step 2). If not, go to Pinpoint Test E, Power Locks.
- Press each button on Keyless Entry keypad. Wait for button to light, then go off, before pushing next button. If each button lights, go to step 3). If no buttons light, go to Pinpoint Test B, Keypad Illumination. If 1 or more buttons fail to light, go to Pinpoint Test C, Keypad Input.
- With ignition off and key out of ignition lock, close all doors and trunk. Make sure all are unlocked, then press buttons 7/8 and 9/0 simultaneously. If all doors lock, go to next step. If some fail to lock, replace module and repeat Quick Test. If all doors fail to lock, go to Pinpoint test C1.
- Unlock driver's door using code. If driver's door unlocks, go to next step. If Driver's door fails to unlock, proceed to Pinpoint Test C1.
- Wait until light on keypad goes out, then re-enter code and press button 3/4 (within 5 seconds) to unlock other door(s). If other door(s) unlock, go to next step. If other door(s) fail to unlock, go to Pinpoint test C1, then repeat Quick Test.
- Wait until light on keypad goes out, then re-enter code and press button 5/6 (within 5 seconds) to unlock trunk. If trunk unlocks, go to next step. If trunk doesn't unlock, go to Pinpoint Test F, Trunk Unlock. If trunk is always unlocked, go to step F5.
- Sit in driver's seat, place transmission selector in"P", close all doors (unlocked), turn interior lights off, then turn ignition on. Move selector to "R", then "D". If all doors lock, go to next step. If some doors fail to lock, go to Pinpoint Test A, Automatic Locking System.
- Open driver's door, then close it. If door locks when closed, go to next step. If not, go to Pinpoint Test A, Automatic Locking System.
- Open driver's door, then depress interior light switch on door jamb with foot. If door locks, go to A15. If door does not lock, go to next step.
- Turn ignition off, place selector in "P" and remove key. Get out of car and close door, then press any keypad button. If interior lights and keyhole lights for both doors come on, go to next step. If not, go to Pinpoint Test D, Illuminated Entry.
- Wait until interior lights go out, then press button to turn them on again. Within 5 seconds, press buttons 7/8 and 9/0 simultaneously to turn off lights. If lights go out, go to next step. If not, go to Pinpoint Test D.
- With ignition off, transmission selector in "P" and driver's door closed, lift outside handle to open door. Within 25 seconds, get in and turn ignition on. If lights come on when handle is lifted and go off when ignition is turned on, go to next step. If lights come on, but do not go out, replace module and repeat Quick Test. If lights do not come on, go to Pinpoint Test D.
NOTE:
In the following steps, no more than 5 seconds should elapse between successive key presses.
