Torque Specifications
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) | |
|---|---|---|
| Pulley Nut | 60-100 (82-136 N.m) | |
| INCH Lbs. (N.m) | ||
| Bearing Retainer Screws | 25-40 (2.8-4.5) | |
| Rectifier Retainer Screws | 40-50 (4.6-5.6) | |
| Terminal Nut | ||
| BAT Terminal | 30-55 (3.4-6.2) | |
| FLD Terminal | 25-35 (2.8-3.9) | |
| GRD Terminal | 25-30 (2.8-4.0) | |
| STA Terminal | 25-35 (2.8-2.9) | |
| Through Bolts | 35-60 (4.1-6.7) | |
