Oxygen Sensor: Service and Repair

***UPDATED BY TSB #93236, NOVEMBER 10, 1993


REMOVAL

1. Disconnect negative battery cable.
2. Disconnect sensor electrical connector.
3. Remove sensor using sensor wrench #TP9P-9472A or equivalent.

Exhaust Gas Oxygen (EGO) Sensor Replacement:

INSTALLATION

1. Install sensor into turbine assembly.
2. Connect sensor electrical connector.
3. Connect negative battery cable.
