Seat Control Switch
Remove seat control switch. Check resistance between terminals with seat control switch in appropriate position. See SEAT CONTROL SWITCH RESISTANCE table. See Fig 1 . If resistances are not as specified, replace seat control switch.
SEAT CONTROL SWITCH RESISTANCE
| Switch Position | Between Terminals No. | Ohms | |
|---|---|---|---|
| Neutral | 8 & All Except 4 | Less Than 5 | |
| Entire Seat | |||
| Down | 2 & 4; 4 & 5 | Less Than 5 | |
| Up | 1 & 4; 3 & 4 | Less Than 5 | |
| Front Up | 1 & 4 | Less Than 5 | |
| Front Down | 4 & 5 | Less Than 5 | |
| Rear Up | 3 & 4 | Less Than 5 | |
| Rear Down | 2 & 4 | Less Than 5 | |
| Seat FWD | 4 & 7 | Less Than 5 | |
| Seat RWD | 4 & 6 | Less Than 5 | |
