Steering Column Multifunction Switch: Notes

WARNING: This page is about a different car, the 2007 Mercury Mariner and 2007 Ford Escape. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Exploded View Of Steering Column Multifunction Switch With Torque Specifications
GF0025620Courtesy of FORD MOTOR CO.
Item Part Number Description
1 - Instrument panel steering column cover
2 W705827 Lower steering column cover mounting screw
3 W705828 Lower steering column cover mounting screws (2 required)
4 3K512 Lower steering column cover
5 3C695 Upper steering column cover
6 W503521 Multi-function switch screws (2 required)
7 14K147 Multi-function switch
