Valve Spring: Installation

WARNING: This page is about a different car, the 2003 Ford Econoline. However, it is still accessible from the selected car via links, so may be relevant.

CAUTION: Components removed should be marked for location. Make sure components are installed in the correct location.

NOTE: Lubricate parts with clean engine oil prior to assembly.

Fig 1: Installing Valve Spring Retainer And Valve Spring

Courtesy of FORD MOTOR CO.

To install, reverse the removal procedure.
