Connecting Rod Bolt/Nut

NOTE: The crankshaft must turn freely, if necessary check and adjust the bearing clearances.

Tighten the connecting rod bearing bolts in two stages.
- Stage 1: 35 Nm
- Stage 2: 90 degrees
