Flywheel: Service and Repair

Flywheel - Manual Transmission

Removal
1. Remove the clutch.





2. Remove the flywheel bolts.

Installation

5.4L - Flywheel Bolt Sequence:

1. Position the flywheel and install the bolts.
Tighten the bolts in two stages:
- Stage 1: Loosely install the bolts.
- Stage 2: Tighten the bolts in the sequence shown.
2. Install the clutch.
