General Specifications
Courtesy of FORD MOTOR CO. FUEL PRESSURE SPECIFICATION
| Item |
Specification |
| Fuel Pressure |
| Key on, engine off |
448 kPa (65 psi) |
| Engine running |
448 kPa (65 psi) |
| Fuel pump output volume per 10 seconds |
125 cc (4.32 oz) |
