System Specifications

Timing chain tensioner-to-cylinder block bolts 12 Nm (9 ft. lbs.)
Crankshaft Pulley bolt 160 Nm (118 ft. lbs.)





Front cover bolts:
Stage 1 7 Nm (62 inch lbs.)
Stage 2 28 Nm (21 ft. lbs.)
