Spark Plug: Service and Repair

SPARK PLUG

REMOVAL
1. Remove the ignition coil-on-plugs.







2. NOTE: LH shown, RH similar.

Remove the LH and RH spark plugs.

3. Inspect the spark plugs.

INSTALLATION
1. To install, the removal procedure.
