Item 19: Fuel Delivery Module Lock Ring Installation Note

  1. Using the special tool, install the fuel delivery module lock ring.
    Fig 1: Installing Fuel Delivery Module Lock Ring Using Special Tool
    G03245200Courtesy of FORD MOTOR CO.
