Occupant Classification Sensor (OCS) Module Connector End View (C3285)
Fig 1: Occupant Classification Sensor (OCS) Module Connector End View (C3285)
Courtesy of FORD MOTOR CO.
Courtesy of FORD MOTOR CO.
