Console - Overhead: Notes

Fig 1: Exploded View Of Console - Overhead Components
GF0038821Courtesy of FORD MOTOR CO.
Item Part Number Description
1 13776 Interior light
2 - Overhead console electrical connectors (2 required) (part of 14335)
3 W505002 Overhead console screws (5 required)
4 045B54 Overhead console
