Block Heater: Notes

WARNING: This page is about a different car, the 2009 Ford Mustang. However, it is still accessible from the selected car via links, so may be relevant.
Material

Item Specification
Motorcraft Premium Gold Engine Coolant with Bittering Agent (bittered in US only)
VC-7-B (US); CVC-7-A (Canada); or equivalent (yellow color)
WSS-M97B51-A1
NOTE: 4.0L shown, 4.6L (3V) and 5.4L similar.
Fig 1: Exploded View Of Block Heater With Torque Specification
GF0046373Courtesy of FORD MOTOR CO.
Item Part Number Description
1 6B019 Block heater electrical connector
2 6A051 Block heater retaining screw
3 6A051 Block heater
