Navigation Diagnostic Screen

WARNING: This page is about a different car, the 2009 Ford Econoline. However, it is still accessible from the selected car via links, so may be relevant.
  1. Turn the in-dash computer on.
  2. Press the navigation icon at the top RH corner of the screen (or press the navigation hardkey).
  3. Press the satellite status icon at the top LH corner of the screen.
    Fig 1: Locating Satellite Status Icon At Top LH Corner Of Screen
    G06144014Courtesy of FORD MOTOR CO.
  4. A list of the current Global Positioning System (GPS) satellites detected is shown in Fig 1.
