Selector Lever Cable: Notes

Selector Lever Cable

Fig 1: Selector Lever Cable Replacement Components With Torque Specifications
G06293302Courtesy of FORD MOTOR CO.
ITEM DESCRIPTION CHART

Item Part Number Description
1 W705443 Exhaust nuts
2 5A262 Exhaust hanger isolators
3 W709729 Exhaust heat shield retainers
4 A11468 Exhaust heat shield
5 4560 Selector lever cable retainer
6 7E395 Selector lever cable
7 7210 Manual control lever
8 5411454 Carpet
9 5401688 Insulation
10 W702751 Selector lever cable grommet nuts
11 - Selector lever cable grommet (part of 7E395)
12 7E364 Selector lever cable retaining bracket
13 - Selector lever cable alignment mark (part of 7E395)
