Output Shaft Speed (OSS) Sensor: Notes

MATERIAL

Item Specification
Motorcraft® MERCON® LV Automatic Transmission Fluid
XT-10-QLVC		 MERCON® LV
Ultra Silicone Sealant
TA-29		 -
Fig 1: Exploded View Of Output Shaft Speed (OSS) Sensor Components With Torque Specifications
G07782853Courtesy of FORD MOTOR CO.
ITEM DESCRIPTION

Item Part Number Description
1 14A464 Transaxle main harness electrical connector
2 9S318 Wiring harness retainer
3 14A163 Wiring harness retainer
4 N805320 Transmission fluid cooler tube nuts
5 7H420 Transmission fluid cooler tube bracket
6 W500213 Main control cover bolts
7 W705619 Main control cover studbolts
8 7G004 Main control cover
9 7B329 Main control-to-cover seal
10 W302863 Main control-to-transaxle case bolt (long) (10 required)
11 W302862 Main control-to-transaxle case bolt (short) (12 required)
12 W520412 Main control nut
13 7A100 Main control assembly
14 7Z490 Main control-to-transaxle case separator plate
15 W713644 Output Shaft Speed (OSS) sensor bolt
16 7H103 OSS sensor
