In-Vehicle Temperature Sensor

In-Vehicle Temperature Sensor









Removal and Installation

1. Remove the center instrument panel finish panel.

2. Disconnect the in-vehicle temperature sensor electrical connector.

3. Rotate the in-vehicle temperature sensor clockwise to detach it from the in-vehicle temperature sensor aspirator hose and remove the in-vehicle temperature sensor.

4. To install, reverse the removal procedure.
