Connecting Rod Bend
WARNING: This page is about a different car, the 2014 Ford F-150. However, it is still accessible from the selected car via links, so may be relevant.
SPECIAL TOOL DESCRIPTION
| Feeler Gauge Set 303-D027 (D81L-4201-A) or equivalent |
NOTE:
Refer to the appropriate Engine article
for the specification.
- Using the Feeler Gauge Set, measure the connecting rod bend on a suitable alignment fixture. Follow the instructions of the fixture manufacturer. Verify the bend measurement is within specification.
