Terminal Not Properly Seated

WARNING: This page is about a different car, the 2014 Ford F-150. However, it is still accessible from the selected car via links, so may be relevant.

= Locked terminal
= Male half
= Female half
= Seal
= Intermittent contact
= Unlocked terminal (Hidden by wire seal)
= Seal

Check for unlocked terminals by pulling each wire at the end of the connector.

Fig 1: Identifying Terminal Not Properly Seated

Courtesy of FORD MOTOR CO.
