| 1 |
* |
* |
Not Used |
|
| 2 |
* |
* |
Not Used |
|
| 3 |
CLF02 (GY-BN) |
20 |
CTRL MOD. - BEAM HIGH LEFT |
|
| 4 |
CMC28 (GY-VT) |
20 |
CTRL MOD. - RELAY DELAY ACCESSORY |
|
| 5 |
CHS02 (YE-BU) |
20 |
CTRL MOD. - HOT/COLD SEAT # DRIVER CUSHION HEATER + |
|
| 6 |
* |
* |
Not Used |
|
| 7 |
CET47 (BU) |
20 |
SWITCH - REVERSE (RS) |
|
| 8 |
CRW09 (BN-BU) |
20 |
SWITCH - FRONT WIPER PARK POSITION |
|
| 9 |
CE436 (VT-OG) |
20 |
CTRL MOD. -WAKE UP PCM |
|
| 10 |
CPL25 (BU-OG) |
20 |
SWITCH - HOOD # AJAR |
|
| 11 |
* |
* |
Not Used |
|
| 12 |
CLS07 (BN-YE) |
20 |
CTRL MOD. - PARK FRONT RIGHT OR FRONT/REAR RIGHT |
|
| 13 |
* |
* |
Not Used |
|
| 14 |
CLS12 (WH-VT) |
20 |
CTRL MOD. - SIDE MARKER |
|
| 15 |
* |
* |
Not Used |
|
| 16 |
CHS07 (GY-BU) |
20 |
CTRL MOD. - HOT/COLD SEAT # PASSENGER CUSHION HEATER + |
|
| 17 |
* |
* |
Not Used |
|
| 18 |
* |
* |
Not Used |
|
| 19 |
* |
* |
Not Used |
|
| 20 |
* |
* |
Not Used |
|
| 21 |
* |
* |
Not Used |
|
| 22 |
* |
* |
Not Used |
|
| 23 |
* |
* |
Not Used |
|
| 24 |
CLS06 (GN-OG) |
20 |
CTRL MOD. - PARK FRONT LEFT OR FRONT/REAR LEFT |
|
