Piston Diameter
WARNING: This page is about a different car, the 2023 Lincoln Nautilus. However, it is still accessible from the selected car via links, so may be relevant.
For information on Ford Color Coded Illustrations refer to OEM COLOR CODING
Check
NOTE:
Refer to the appropriate Engine article
for the specification.
- Measure the piston diameter 90 degrees from the piston pin and down from the top of the piston to the point indicated.
