Sensor-Exhaust Differential Pressure

Component ID: 457
Component : SENSOR-EXHAUST DIFFERENTIAL PRESSURE

Connector:
Name : SENSOR-EXHAUST DIFFERENTIAL PRESSURE
Color :
# of pins : 5
Gender : FEMALE




Pin Description Circuit
1 EXHAUST DIFFERENTIAL PRESSURE SENSOR SIGNAL 1264 20DB/PK
2 EXHAUST DIFFERENTIAL PRESSURE SENSOR GROUND 1263 20BR/DB
3 EXHAUST DIFFERENTIAL PRESSURE SENSOR 5 VOLT SUPPLY 1265 20PK/DB
4 - -
5 - -
