Symptom Related Diagnostic Procedures

Temperature Control Effort:

A kinked control cable, a binding valve or a faulty control assembly are possible causes of excessive temperature control lever effort. For an organized diagnosis procedure and an effective "fix" for too little temperature control effort, refer to accompanying figure.
