Installation Procedure

WARNING: This page is about a different car, the 2005 Cadillac STS. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: View Of Data Link Connector

Courtesy of GENERAL MOTORS CORP.

Locate the connector to the I/P.

NOTE: Refer to Fastener Notice in Cautions and Notices.

Install the screws (1) securing the connector to the I/P.
Tighten: Tighten the screws (1) to 2 N.m (18 lb in).
Install the knee bolster trim. Refer to Knee Bolster Replacement in Instrument Panel, Gages, and Console.
