Fuel Filter Replacement

The fuel filter should be replaced whenever the fuel pressure drops below the specified value, see Fuel Pressure Test  after making sure that the fuel pump and the fuel pressure regulator are OK.

1. Remove the fuel tank unit. See '99-00 Models  or '01-04 Models  .
2. Remove the fuel filter (A).
   Fig 1: Removing Fuel Filter

   Courtesy of AMERICAN HONDA MOTOR CO., INC.
3. Check these items before installing the fuel tank unit:
   • When connecting the wire harness, make sure the connection is secure and the terminal (B) is firmly locked into place.
   • Do not push the lower part of the suction filter (C).
   • When installing the fuel gauge sending unit (D), make sure the connection is secure and the connector is firmly locked into place. Be careful not to bend or twist it excessively.
4. Install the parts in the reverse order of removal with a new base gasket (E). When installing the fuel tank unit, align the marks on the unit and the fuel tank. See Fuel Pump Replacement .
   NOTE: Place the new base gasket for the fuel tank unit on the tank first, then carefully insert the fuel tank unit. If the fuel tank unit is incorrectly installed, the MIL can come on with DTC P1456.
