VSA Modulator-Control Unit Removal and Installation: Removal

Push down the lock (A) on the VSA modulator-control unit 47P connector (B), and remove the connector.

Fig 1: Pushing Down Lock On VSA Modulator-Control Unit 47P Connector
Courtesy of AMERICAN HONDA MOTOR CO., INC.
Disconnect the six brake lines from the VSA modulator-control unit (C).
Remove the three 6 mm bolts, then remove the VSA modulator-control unit with bracket (D) from the body.
Remove the three hex bolts, then remove the VSA modulator-control unit from the bracket.
