Switch Check

Each switch must be shown on the display and each switch must reverse and sound, when touched.

NOTE: The test may be affected if done in direct sunlight.

Fig 1: Identifying Switch Check Screen Display

Courtesy of AMERICAN HONDA MOTOR CO., INC.
