Torque Specifications

Cylinder Head




If either diameter is less than 8.6 mm (0.34 in.), replace the cylinder head bolt.




Tighten the cylinder head bolts in sequence to 29 N.m (3.0 kgf.m, 22 lbf.ft).




Tighten all cylinder head bolts an additional 130°.


Intake Manifold

Intake Manifold:

Camshaft Sprocket





Exhaust Manifold
