Climate Control Unit Removal/Installation (With Climate Control)

Climate Control Unit Removal/Installation

1. Remove the instrument panel. Instrument Panel Removal/Installation

2. Remove the self-tapping screws and the climate control unit (A). If necessary, replace the bulbs (B).

3. Install the control unit in the reverse order of removal. After installation, operate the various functions to see whether works properly.

4. Run the self-diagnostic function to confirm that there are no problems in the system. How to Troubleshoot the Climate Control System
