USB Adapter Unit Connector End View (USB Adapter) (View 229)

Rear of Center Console
Connector A
- WHT
- On USB Unit Sub-harness (Factory)
- On USB Harness (Honda Accessory)
Fig 1: USB Adapter Unit (USB Adapter) Connector Terminal - Connector A (View 229)
Courtesy of AMERICAN HONDA MOTOR CO., INC.

Connector B
- GRY
- On USB Adapter Sub-harness
Fig 2: USB Adapter Unit (USB Adapter) Connector Terminal - Connector B (View 229)
Courtesy of AMERICAN HONDA MOTOR CO., INC.
