Auxiliary Under-Hood Fuse/Relay Box (B)

Fig 1: Auxiliary Under-Hood Fuse/Relay Box (B) Component Locations

Courtesy of HONDA, U.S.A., INC.

Auxiliary Under-Hood Fuse/Relay Box (B) Legend

Socket	Ref	Terminals	Connects to	Notes
T2	1	---	Left engine compartment wire harness
T3	2	---	Left engine compartment wire harness
